The Karcher Puzzi 10/1 Spray Extraction Cleaner & Powder with upholstery nozzle and floor nozzle is particularly suited to hygienic and effective cleaning of small to medium size textile surfaces.
With 1 bar spray pressure, this spray extraction machine ensures gentle, deep cleaning of textiled surfaces and delivers impressive results, especially when cleaning carpets and upholstery.
Thanks to the narrow floor nozzle, the machine is optimally suited for use in confined spaces. The flexible suction lips allow cluttered areas to be cleaned easily as they follow the contour of the floor, without being affected by the holding position and height of the user.
The Kärcher Puzzi 10/1 Carpet & Upholstery Cleaner is fitted with an integrated cable hook and a holder for the suction tube on the handle, allowing it to be carried in 1 hand. The suction pipe can be stored in the fresh water tank and trigger and upholstery nozzle can be stored in the dirty water compartment while being transported or when the machine is not in use.
For best results in cleaning carpets and upholstery we recommend Kärcher RM 760, more commonly known as Puzzi powder. This powder is mixed into the water and dissolves heavy oil, grease and mineral stains and has a gentle cleaning action at all temperature ranges. Kärcher RM 760 improves floor hygiene and is free from bleaching agents with a pleasant, fresh fragrance.
Optimal suitability for daily use
Tool-free adjustment of the grip; Accessory/cable fastenings; quick change from floor to upholstery nozzle.
Removable dirty water tank
The dirty water tank is easy to remove and can also be used for filling the fresh water tank.
Diverse use
Various accessories for diverse applications (e.g. crevice nozzle for cleaning car seats and upholstery).
Ergonomic second handle
Ergonomic handle and lightweight design for ease of operation.
Height-adjustable handle.
Technical data
| Max. area performance (m²/h) | 20 – 25 |
| Air flow rate (l/s) | 54 |
| Vacuum (mbar/kPa) | 220 / 22 |
| Spray rate (l/min) | 1 |
| Spray pressure (bar) | 1 |
| Fresh/dirty water tank (l) | 10 – 9 |
| Turbine power (W) | 1250 |
| Pump power (W) | 40 |
| Voltage (V) | 220 – 240 |
| Frequency (Hz) | 50 – 60 |
| Weight (kg) | 10.7 |
| Dimensions (L × W × H) (mm) | 690 x 325 x 440 |
Equipment on the Karcher Puzzi 10/1 Spray Extraction Cleaner & Powder
- Spray hose with integrated water feed, 2.5 m
- Integral accessory holder for manual nozzle
- Upholstery nozzle
- Additional handle
- Cable hook
- Narrow floor nozzle with flexible suction lip
- Handle with trigger
- 800 g RM 760 Puzzi powder
